二刷 K8s 源码 - workqueue 的所有细节

1
2
3
4
5
6
7
8
9

type Interface interface {
	Add(item interface{})
	Len() int
	Get() (item interface{}, shutdown bool)
	Done(item interface{})
	ShutDown()
	ShutDownWithDrain()
	ShuttingDown() bool
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18

type Type struct {
	// queue defines the order in which we will work on items. Every
	// element of queue should be in the dirty set and not in the
	// processing set.
	queue []t

	// dirty defines all of the items that need to be processed.
	dirty set

	// Things that are currently being processed are in the processing set.
	// These things may be simultaneously in the dirty set. When we finish
	// processing something and remove it from this set, we'll check if
	// it's in the dirty set, and if so, add it to the queue.
	processing set

	cond *sync.Cond
    // ......
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20

func (q *Type) Add(item interface{}) {
	q.cond.L.Lock()
	defer q.cond.L.Unlock()
	if q.shuttingDown {
		return
	}
	if q.dirty.has(item) {
		return
	}

	q.metrics.add(item)

	q.dirty.insert(item)
	if q.processing.has(item) {
		return
	}

	q.queue = append(q.queue, item)
	q.cond.Signal()
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

func (q *Type) Get() (item interface{}, shutdown bool) {
	q.cond.L.Lock()
	defer q.cond.L.Unlock()
	for len(q.queue) == 0 && !q.shuttingDown {
		q.cond.Wait()
	}
	if len(q.queue) == 0 {
		// We must be shutting down.
		return nil, true
	}

	item = q.queue[0]
	// The underlying array still exists and reference this object, so the object will not be garbage collected.
	q.queue[0] = nil
	q.queue = q.queue[1:]

	q.metrics.get(item)

	q.processing.insert(item)
	q.dirty.delete(item)

	return item, false
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14

func (q *Type) Done(item interface{}) {
	q.cond.L.Lock()
	defer q.cond.L.Unlock()

	q.metrics.done(item)

	q.processing.delete(item)
	if q.dirty.has(item) {
		q.queue = append(q.queue, item)
		q.cond.Signal()
	} else if q.processing.len() == 0 {
		q.cond.Signal()
	}
}

1
2
3
4
5

type DelayingInterface interface {
	Interface
	// AddAfter adds an item to the workqueue after the indicated duration has passed
	AddAfter(item interface{}, duration time.Duration)
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20

func (q *delayingType) AddAfter(item interface{}, duration time.Duration) {
	// don't add if we're already shutting down
	if q.ShuttingDown() {
		return
	}

	q.metrics.retry()

	// immediately add things with no delay
	if duration <= 0 {
		q.Add(item)
		return
	}

	select {
	case <-q.stopCh:
		// unblock if ShutDown() is called
	case q.waitingForAddCh <- &waitFor{data: item, readyAt: q.clock.Now().Add(duration)}:
	}
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13

func newDelayingQueue(clock clock.WithTicker, q Interface, name string, provider MetricsProvider) *delayingType {
	ret := &delayingType{
		Interface:       q,
		clock:           clock,
		heartbeat:       clock.NewTicker(maxWait),
		stopCh:          make(chan struct{}),
		waitingForAddCh: make(chan *waitFor, 1000),
		metrics:         newRetryMetrics(name, provider),
	}

	go ret.waitingLoop()
	return ret
}

1
2
3
4
5
6

type waitFor struct {
	data    t
	readyAt time.Time
	// index in the priority queue (heap)
	index int
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87

func (q *delayingType) waitingLoop() {
	defer utilruntime.HandleCrash()

	// Make a placeholder channel to use when there are no items in our list
	never := make(<-chan time.Time)

	// Make a timer that expires when the item at the head of the waiting queue is ready
	var nextReadyAtTimer clock.Timer

	// 这是一个优先级队列，用一个最小堆保存了所有 waitFor（waitForPriorityQueue 的类型是 []*waitFor）
	waitingForQueue := &waitForPriorityQueue{}
	heap.Init(waitingForQueue)

	waitingEntryByData := map[t]*waitFor{}

	// 后面的所有逻辑都在这个 for 循环里
	for {
		if q.Interface.ShuttingDown() {
			return
		}

		now := q.clock.Now()

		// Add ready entries
		// 一直判断 waitingForQueue 这个堆里有没有元素，如果有，就 Peek 出来第一个元素看是不是 ready，如果 ready
		// 那就通过 q.Add() 方法将其数据放入队列（也就是前文那个 Queue 实现的 Add 逻辑）
		for waitingForQueue.Len() > 0 {
			entry := waitingForQueue.Peek().(*waitFor)
			if entry.readyAt.After(now) {
				break
			}

			entry = heap.Pop(waitingForQueue).(*waitFor)
			q.Add(entry.data)
			delete(waitingEntryByData, entry.data)
		}

		// Set up a wait for the first item's readyAt (if one exists)
		// 代码到这里也就是说前面一个 for 里的 break 被执行了，换言之最小堆中的最小元素，也就是最快 ready 的一个都还没有 ready；
		// 这里将 nextReadyAtTimer 计时器的时间设置为（最快 ready 的第一个元素的 ready 时间 - 当前时间），
		// 这样当 nextReadyAt 这个 channel 有数据的时候，最小堆里的第一个元素也就 ready 了。
		nextReadyAt := never
		if waitingForQueue.Len() > 0 {
			if nextReadyAtTimer != nil {
				nextReadyAtTimer.Stop()
			}
			entry := waitingForQueue.Peek().(*waitFor)
			nextReadyAtTimer = q.clock.NewTimer(entry.readyAt.Sub(now))
			nextReadyAt = nextReadyAtTimer.C()
		}

		// 刚才设置好了一个合适的 nextReadyAt，现在开始 select 等待某个 channel 有反应
		select {
		case <-q.stopCh:
			return
		// 心跳时间是10s
		case <-q.heartbeat.C():
			// continue the loop, which will add ready items
		// 执行到这里也就是第一个 item ready 了
		case <-nextReadyAt:
			// continue the loop, which will add ready items

		// 当有元素被通过 AddAfter() 方法加进来时，waitingForAddCh 就会有内容，这时候会被取出来；
		// 如果没有 ready，那就调用 insert（大概率主要就是插入最小堆的过程）；如果 ready 了那就直接 Add 到 Queue 里。
		case waitEntry := <-q.waitingForAddCh:
			if waitEntry.readyAt.After(q.clock.Now()) {
				insert(waitingForQueue, waitingEntryByData, waitEntry)
			} else {
				q.Add(waitEntry.data)
			}
			// 通过一个循环将 waitingForAddCh 中的所有元素都消费掉，根据 ready 情况要么插入最小堆（优先级队列），要么直接入队。
			drained := false
			for !drained {
				select {
				case waitEntry := <-q.waitingForAddCh:
					if waitEntry.readyAt.After(q.clock.Now()) {
						insert(waitingForQueue, waitingEntryByData, waitEntry)
					} else {
						q.Add(waitEntry.data)
					}
				default:
					drained = true
				}
			}
		}
	}
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15

// RateLimitingInterface is an interface that rate limits items being added to the queue.
type RateLimitingInterface interface {
	DelayingInterface

	// AddRateLimited adds an item to the workqueue after the rate limiter says it's ok
	AddRateLimited(item interface{})

	// Forget indicates that an item is finished being retried.  Doesn't matter whether it's for perm failing
	// or for success, we'll stop the rate limiter from tracking it.  This only clears the `rateLimiter`, you
	// still have to call `Done` on the queue.
	Forget(item interface{})

	// NumRequeues returns back how many times the item was requeued
	NumRequeues(item interface{}) int
}

1
2
3
4

// AddRateLimited AddAfter's the item based on the time when the rate limiter says it's ok
func (q *rateLimitingType) AddRateLimited(item interface{}) {
	q.DelayingInterface.AddAfter(item, q.rateLimiter.When(item))
}

1
2
3

func (q *rateLimitingType) Forget(item interface{}) {
	q.rateLimiter.Forget(item)
}

1
2
3
4
5
6
7
8
9

type RateLimiter interface {
	// When gets an item and gets to decide how long that item should wait
	When(item interface{}) time.Duration
	// Forget indicates that an item is finished being retried.  Doesn't matter whether it's for failing
	// or for success, we'll stop tracking it
	Forget(item interface{})
	// NumRequeues returns back how many failures the item has had
	NumRequeues(item interface{}) int
}

1
2
3
4
5
6
7

func DefaultControllerRateLimiter() RateLimiter {
	return NewMaxOfRateLimiter(
		NewItemExponentialFailureRateLimiter(5*time.Millisecond, 1000*time.Second),
		// 10 qps, 100 bucket size.  This is only for retry speed and its only the overall factor (not per item)
		&BucketRateLimiter{Limiter: rate.NewLimiter(rate.Limit(10), 100)},
	)
}

1
2
3

func NewMaxOfRateLimiter(limiters ...RateLimiter) RateLimiter {
	return &MaxOfRateLimiter{limiters: limiters}
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19

// MaxOfRateLimiter calls every RateLimiter and returns the worst case response
// When used with a token bucket limiter, the burst could be apparently exceeded in cases where particular items
// were separately delayed a longer time.
type MaxOfRateLimiter struct {
	limiters []RateLimiter
}

func (r *MaxOfRateLimiter) When(item interface{}) time.Duration {
	ret := time.Duration(0)
	for _, limiter := range r.limiters {
		curr := limiter.When(item)
		// 拿到最久的限速时长
		if curr > ret {
			ret = curr
		}
	}

	return ret
}

1
2
3
4
5
6
7

func DefaultControllerRateLimiter() RateLimiter {
	return NewMaxOfRateLimiter(
		NewItemExponentialFailureRateLimiter(5*time.Millisecond, 1000*time.Second),
		// 10 qps, 100 bucket size.  This is only for retry speed and its only the overall factor (not per item)
		&BucketRateLimiter{Limiter: rate.NewLimiter(rate.Limit(10), 100)},
	)
}
